ARTICULATING JLG - 600AJ 600AJ Boom Lift
$0.00
Product Details
600AJ Boom Lift w/Jib, 60 ft
Articulating Jib provides +70 degrees to -60 degrees of motion relative to the main boom.
Articulating boom lifts (knuckle booms) are used for reaching up and over machinery, equipment, and other obstacles mounted on floors, and for reaching other elevated positions not easily approached by a straight (telescopic) boom lift. The machine's turntable may be rotated 360 degrees in either direction. The boom can be raised or lowered from vertical to below horizontal, and extended (telescoped) while the work platform remains horizontal and stable. It can be maneuvered forward or backward and steered in any direction by the operator from the work platform, even while the basket is elevated. All articulating models are driveable at full elevation and have chassis widths that provide access to narrow industrial aisleways and congested work areas. Easy to use platform controls for reduced operator training time. Advanced boom design provides optimal reach envelope with zero tailswing. Easy access swing-out engine tray. Optional oscillating axle and four-wheel drive for superior traction Platform capacity of up to 1,000 lb (450 kg).
SPECIFICATIONS
Make:JLG
Model:600AJ
FUEL: Diesel
FUEL TANK: 30 Gal
GRADABILITY: 30%
GROUND-CLEARANCE: 12 in.
HEIGHT STOWED: 8 ft 4 in.
HORIZONTAL OUTREACH: 39 ft 9 in.
LENGTH STOWED: 28 ft 11.5 in.
LIFT CAPACITY MAX: 1000 lbs
LIFT CAPACITY MAX HEIGHT: 500 lb
LIFT CAPACITY MAX REACH: 500 lb
PLATFORM CAPACITY: 500 lb
PLATFORM HEIGHT: 60 ft.
PLATFORM SIZE: 36 x 96 in.
PLATFORM-WEIGHT-CAP-RESTRICTD 1000 lbs.
PLATFORM-WEIGHT-CAP-UN-RESTRICTD: 500 lbs
SPEED: 3.6 mph
WEIGHT: 22,200 lbs
